The near-infinite elasticity of Amazon's EC2 service is amazing. You can easily and cheaply spin up new instances whenever you need them. At LaunchDarkly, we provision new instances every time we deploy a new version of one of our services, which often happens multiple times in a day. We use Ansible to orchestrate the provisioning and deploy process, which means that we have easily repeatable deploys, and no server is a snowflake. Using the 'cattle, not pets' mindset, we routinely create and destroy instances. The script basically does the following steps:

  1. Provisions a fresh set of instances using a base AMI image that we have created
  2. Pulls down the latest code and config files from S3 (which is where our build server publishes to)
  3. Runs a few smoke tests to be sure the app has started up
  4. Swaps the load balancer configuration so the load balancers start sending traffic to the new instances
  5. Waits for the old instances to finish processing any requests that they had received before the load balance switch
  6. De-provisions the instances running the old version of the code

Note that the de-provisioning happens last. If something goes wrong in this process (the most common place for problems is that we forgot to update the production configuration file, so the app doesn't start properly, so the smoke tests in step 3 fail), then there will be instances left running that are not in the load balancer. Usually, we just fix the config and re-run the ansible script, and everything cleans up nicely, but sometimes some old instances can get left behind. Also, sometimes the provisioning in step 1 can get interrupted, resulting in the new instances just sitting there.

These problems are pretty rare, but they can be insidious because an instance happily sitting there doing nothing will not raise any alarms with our monitoring systems. They will just sit there racking up the bill.

Get control of your zombie EC2 instances

In order to detect these 'zombie' instances, I wrote a quick python script that hits each of our services through the load balancer to determine what the 'live' version is, and then traverses the EC2 API to inspect instance tags looking for instances that are running the wrong version of the code. It then publishes an alert to an SNS topic. On our team, we have these notifications email the team and post a message in HipChat. We have this script run as a Lambda function hourly.

Since this might be useful to other teams too, I wanted to share it. Read on to see how you can set it up for your own environment. Please let us know if you find it useful!

Assumptions

This script makes use of tags on the EC2 instances to determine if an instance is doing good work, or is languishing, undead. It also assumes you are using load balancers to find the 'live' instances (ELBs are fine for this, or really just any way to have a stable URL to discover the right instances). If these assumptions don't hold for your environment, you may need to make some additional tweaks.

Getting started

There are a few things you need to do to set this up for yourself. After cloning the code from https://github.com/launchdarkly/legendre, copy the custom_example.py to custom.py, and fill it in for your environment.

  • Set notify_sns_topic_name to the SNS topic that you want to use. It's okay if it doesn't exist yet; the script can create it, but you will still need to set the subscriptions to do something useful.
  • Set up the app_status_resources dict to define the applications and tiers in your system. The URLs are meant to be status check resources (via a load balancer) that can be used to get the running version.
  • Define get_expected_sha to determine what is the 'current' version of the given application in a given tier. Any different version will be deemed a zombie.

Also, the deploy needs a few environment variables set. Edit vars.sh to set the subnet and security group for the lambda function to run inside your VPC.

Run the deploy script

When you are ready to deploy, run ./deploy_lambda_function.sh. This will:

  • Package up the script with its dependencies into the zip format that AWS Lambda expects (as defined in pacakge.sh).
  • Interact with the AWS API to set up the lambda function with most of the things it needs (as defined in scripts/setup_lambda.py):
    undefinedundefined

However, there are a couple of things you still need to do:

  • Add subscribers to the SNS topic. This will be highly personalized to your needs. Maybe you want an email sent. Maybe you want a webhook to notify your team in HipChat. Maybe you want it to trigger another lambda function that will kill the zombie instances. Maybe you want it to sound an air-raid siren. I'll leave this as an exercise to the reader.

EDIT: Thanks to Twitter user @chiradeep for the tip on how to set up Cloudwatch events to trigger a lambda task via the API.  I've updated the script to take care of this.
